产品详情
产品优势
1、体成型焊接机架
整体焊接和退火处理的机架，长期稳定和可靠
The integrated bed with overall welding and annealingtreatmentis long-term stable and reliable
2、主锯台面气浮台装置
配主锯台表面气浮装置可以有效避免因板材重量过大而造成的板材表面划伤(选配)
The main saw table surface air flotation device can effectissive weight of the board(Optional)
vely avoid scratches on the board surface caused by exce
3、双抓手同步
双夹手同步技术可以同时锯切不同长度和宽度的木板，在提高时间和效率的同时节省能源(选配)
Dual gripper synchronization technology can simultaneously cut boards of different lengths and widths,
saving energy while improving time and efficiency(Optional)
技术参数
| 机器型号Model | KS-380Q |
|---|---|
| 锯切长度Cutting length | 3800mm |
| 锯切宽度Sawing width | 3800mm |
| 锯切厚度Sawing thickness | 120mm |
| 定位方式Targeting | 自动 |
| 定位精度Positioning accuracy | +0.02mm |
| 锯切精度Sawing accuracy | +0.15mm |
| 主锯电机功率Main saw motor power | 22kw |
| 主锯片外径Main saw blade outer diameter | 400-480mm |
| 主锯轴直径Main saw shaft diameter | 75mm |
| 主锯转速Main saw speed | 4100r/min |
| 锯车牵引电机功率Saw car traction motor power | 2kw |
| 机械手伺服电机Robot servo motor | 2kw |
| 副锯电机功率Vice saw motor power | 2.2kw |
| 副锯片外径Vice saw blade outer diameter | 220mm |
| 副锯轴直径Vice saw shaft diameter | 50mm |
| 副锯转速Sub saw speed | 6200/min |
| 送料速度Feeding speed | 0-90m/min |
| 锯切速度Sawing speed | 0-90m/min |
| 回程速度Return speed | 0-120m/min |
| 空气压力Air pressure | 0.6-0.8MPA |
| 离心风机Centrifugal fan | 5kw |
| 总功率Total power | 35.15kw |
| 外形尺寸Dimensions | 6400*5700*2000mm |
