产品详情
产品优势
四轴加工中心(门墙柜、圆弧一体机)
180°旋转主轴
可轻松完成传统固定主轴难以实现的工艺，比如圆弧门板铣型，45°切割、钻孔、木门规方
门锁加工以及水平侧面铣型等工艺，满足定制家具板材加工中多样化的造型需求。
This machine can easily perform processes that are difficult for traditional fixed spindle machines such as arc-shapeddoor panel milling.
45-degree cutting. drilling, square-shaped door panel processing. lock processing. and horizontalside milling.
thus meeting the diverse molding requirements in custom furniture and sheet material processing
技术参数
| 机器型号Model | KH-908TD |
|---|---|
| 加工范围Processing scope | 1300*2800mm |
| 最大加工尺寸Maximum machining size | 1300*2800mm |
| 最大加工速度Maximum processing speed | 25m/min |
| 传动形式Transmission form | X/Y齿条;Z丝杆 |
| 台面结构Table structure | 分区吸附台面 |
| 主轴功率Spindle power | 9kw |
| 主轴转速Spindle speed | 18000/24000r/min |
| 快移速度Fast moving speed | 80m/min |
| 垂直排钻组Vertical drilling group | - |
| 刀库容量Magazine capacity | 24把 |
| 总功率Total power | 19kw |
| 工作电压working voltage | AC380V/50Hz |
| 驱动系统driving system | 伺服 |
| 外形尺寸External dimensions | 4270*2550*3030mm |
