产品详情
产品优势
加厚钢材+高横梁设计，抗振性极佳，连续加工无变形，适
用于24小时高强度生产。
Thick steel sheets and high cross beams ensure excellent vibrationresistance, continuous processing without deformation, and suitability.It is designed for 24-hour high-intensity production..
独特钻包设计
独创箱体结构，维修无需整体拆包，大幅缩短停机时
间，寿命较传统设计提升50%以上。
The unique box structure allows for maintenance without the need todisassemble the entire unit, thereby significantly reducing downtimeThe lifespan has been extended by more than 50% compared totraditional designs..
可调偏心轮夹具
快速微调夹手位置，适配不同厚度板材
Quickly fine-tune the clamping position to adaptation different
thickness sheets of material.
技术参数
| 机器型号Model | CD-612BS |
|---|---|
| 铣槽加工配置Milling slot configuration | 有 |
| 主轴形式Router(collect type) | Er32 |
| 刀柄直径Tool diameter | 10,1/2mm |
| 主轴电机功率Router power | 3.5kwx2 |
| 主轴转速Rotation speed | 18000rpm |
| 垂直钻Vertical spindle | 7*2(上钻)6(下钻) |
| 水平钻Horizontal spindle | 4+4，总共8把 |
| 钻组电机功率Boring head powe | 2.2kwx3 |
| 板材加工厚度Sheet processing width | 10-55mm |
| 板材加工宽度Sheet processing thickness | 40-1220mm |
| 板材加工长度Sheet processing length | 200-3000mm |
| 工作电压Working voltage | 380V.50Hz |
| 工作气压Working air pressure | 0.6-0.8Mpa |
| 包装尺寸Package size | 5400x2700x1860(mm) |
| 总功率lotal power | 23kw |
